OKDH-T/20-W12-001-C
ActiveMurata Power Solutions Inc.
DC DC CONVERTER 0.6-3.3V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OKDH-T/20-W12-001-C
ActiveMurata Power Solutions Inc.
DC DC CONVERTER 0.6-3.3V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | OKDH-T/20-W12-001-C | OKDH-T Series |
|---|---|---|
| Applications | ITE (Commercial) | ITE (Commercial) |
| Control Features | Active High, Enable | Active High, Enable |
| Current - Output (Max) [Max] | 20 A | 20 - 50 A |
| Efficiency | 93.6 % | 93.6 - 94.6 % |
| Features | OCP, UVLO, OTP, Remote On/Off, SCP, OVP | OCP, UVLO, OTP, Remote On/Off, SCP, OVP |
| Mounting Type | Through Hole | Through Hole |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 15-DIP Module | 20-DIP Module, 15-DIP Module |
| Size / Dimension [x] | 25.7 mm | 25.7 - 31 mm |
| Size / Dimension [x] | 1.01 in | 1.01 - 1.22 in |
| Size / Dimension [y] | 13.8 mm | 13.8 - 20 mm |
| Size / Dimension [y] | 0.54 " | 0.54 - 0.79 " |
| Size / Dimension [z] | 0.32 " | 0.32 - 0.33 in |
| Size / Dimension [z] | 8.2 mm | 8.2 - 8.5 mm |
| Type | Non-Isolated PoL Module, Digital | Non-Isolated PoL Module, Digital |
| Voltage - Input (Max) [Max] | 14 V | 14 V |
| Voltage - Input (Min) [Min] | 4.5 V | 4.5 V |
| Voltage - Output 1 [Max] | 3.3 V | 3.3 V |
| Voltage - Output 1 [Min] | 0.6 V | 0.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
OKDH-T Series
DC DC CONVERTER 0.6-3.3V 165W
| Part | Voltage - Input (Min) [Min] | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Voltage - Input (Max) [Max] | Package / Case | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) [Max] | Number of Outputs | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Mounting Type | Type | Control Features | Features | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. OKDH-T/50-W12-001-C | 4.5 V | 0.6 V | 3.3 V | 14 V | 20-DIP Module | ITE (Commercial) | 125 °C | -40 °C | 50 A | 1 | 1.22 in | 8.5 mm | 0.79 " | 20 mm | 0.33 in | 31 mm | Through Hole | Non-Isolated PoL Module, Digital | Active High, Enable | OCP, OTP, OVP, Remote On/Off, SCP, UVLO | 94.6 % |
Murata Power Solutions Inc. OKDH-T/20-W12-001-C | 4.5 V | 0.6 V | 3.3 V | 14 V | 15-DIP Module | ITE (Commercial) | 125 °C | -40 °C | 20 A | 1 | 1.01 in | 8.2 mm | 0.54 " | 13.8 mm | 0.32 " | 25.7 mm | Through Hole | Non-Isolated PoL Module, Digital | Active High, Enable | OCP, OTP, OVP, Remote On/Off, SCP, UVLO | 93.6 % |
Description
General part information
OKDH-T Series
Non-Isolated PoL Module, Digital DC DC Converter 1 Output 0.6 ~ 3.3V 20A 4.5V - 14V Input
