Part	Termination Style	Rotational Life (Cycles Min)	Orientation	Pulses per Revolution	Output Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Encoder Type	Mounting Type	Actuator Type	Built in Switch	Detent
Sensata-BEI Encoders 01070-581	Connector	7.5 B	User Selectable	4096	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-863	Connector	7.5 B	User Selectable	100	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-120	Connector	7.5 B	User Selectable	1024	Quadrature with Index (Incremental)	28 V	5 V	Incremental	Servo Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-509	Connector	7.5 B	User Selectable	100	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-1206	Connector	7.5 B	User Selectable	1024	Quadrature with Index (Incremental)	28 V	5 V	Incremental	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-319	Connector	7.5 B	User Selectable	2048	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-294	Connector	7.5 B	User Selectable	1024	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-273	Connector	7.5 B	User Selectable	360	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-232	Connector	7.5 B	User Selectable	5000	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No
Sensata-BEI Encoders 01070-230	Connector	7.5 B	User Selectable	500	Quadrature with Index (Incremental)	28 V	5 V	Optical	Chassis Mount	Hole for Shaft	No	No

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

No documents available
