Part	Operating Pressure	Output Type	Applications	Termination Style	Operating Temperature (Min)	Operating Temperature (Max)	Pressure Type	Accuracy	Port Feature	Port Gender	Port Diameter	Maximum Pressure	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Output Bits	Package / Case	Port Style	Voltage - Supply	Output Voltage (Min)	Output Voltage (Max)	Features
TE Connectivity AMP Connectors 89BSD-012BS-5
TE Connectivity AMP Connectors 89BSD-012BA-4
TE Connectivity AMP Connectors 89BSD-018BA-B
TE Connectivity AMP Connectors 89-10KA-0P
TE Connectivity AMP Connectors 89BSD-006BS-A	87.02 PSI	Digital - I2C	Industrial Automation	PC Pins	-40 °C	85 °C	Sealed Gauge	0.3 %	UNEF	Male	0.3125 in	174.05 PSI	3.6 V	1.8 V	24 b	Cylinder	Threaded
TE Connectivity AMP Connectors 89-01KA-0U	1000 PSI	Wheatstone Bridge	Board Mount	PC Pin	-40 °C	125 °C	Absolute	0.25 %				3000 PSI				Cylinder	No Port	9.5 V	0 V	208 mV
TE Connectivity AMP Connectors 89BSD-018BA-A
TE Connectivity AMP Connectors 89-10KA-0U	10000 PSI	Wheatstone Bridge	Board Mount	PC Pins	-40 °C	125 °C	Absolute	0.25 %				30000 PSI				Cylinder	No Port	9.5 V	0 V	100 mV
TE Connectivity AMP Connectors 89BSD-006BA-B	87.02 PSI	I2C	Industrial Automation	Cable with Connector	-40 °C	85 °C	Absolute	0.3 %				174.05 PSI	3.6 V	1.8 V	24 b	Cylinder	No Port
TE Connectivity AMP Connectors 89-05KS-4R	5000 PSI	Wheatstone Bridge	Board Mount	PC Pin	-40 °C	125 °C	Sealed Gauge	0.25 %	NPT	Male	0.25 "	15000 PSI				Cylinder	Threaded		0 V	125 mV	Temperature Compensated

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
