Specification	9BMB12H2D01

Air Flow	39.2 CFM
Approval Agency	cURus, TUV
Bearing Type	Ball
Fan Type	Blower
Features	Locked Rotor Sensor
Noise	57 dB
Operating Temperature (Max)	158 °F
Operating Temperature (Min)	-4 °F
Power (Watts)	13.2 W
RPM	4850 RPM
Size / Dimension Height	95 mm
Size / Dimension Length	97.1 mm
Size / Dimension Shape	Rectangular/Rounded
Static Pressure	1.968 in H2O
Termination	3 Wire Leads
Termination Leads Count	3
Termination Type	Wire Leads
Voltage - Rated	12 VAC
Weight	0.419 lb
Width	33 mm

9BMB Type Series

Part	Weight	Bearing Type	Approval Agency	Fan Type	Air Flow	Static Pressure	Size / Dimension Shape	Size / Dimension Height	Size / Dimension Length	Voltage - Rated	Termination Leads Count	Termination Type	Termination	Features	Power (Watts)	Operating Temperature (Min)	Operating Temperature (Max)	Noise	RPM	Width	Lifetime	Current Rating	Material - Frame	Voltage Range (Max)	Voltage Range (Min)	Material - Blade
Sanyo Denki America Inc. 9BMB12G201	0.419 lb	Ball	cURus TUV	Blower	47.3 CFM	3.052 in H2O	Rectangular/Rounded	95 mm	97.1 mm	12 VAC	3	Wire Leads	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	21.6 W	-4 °F	158 °F	61 dB	5750 RPM	33 mm	40000 Hrs	1.8 A	Plastic	13.8 VDC	7 V	Plastic
Sanyo Denki America Inc. 9BMB12P2H01	0.419 lb	Ball	cURus TUV	Blower	39.2 CFM	1.968 in H2O	Rectangular/Rounded	95 mm	97.1 mm	12 VAC	4 leads	Wire Leads	4 Wire Leads	Locked Rotor Protection PWM Control Speed Sensor (Tach)	13.2 W	-4 °F	158 °F	57 dB	4850 RPM	33 mm	40000 Hrs	1.1 A	Plastic	13.8 VDC	10.2 VDC	Plastic
Sanyo Denki America Inc. 9BMB12H201	0.419 lb	Ball	cURus TUV	Blower	39.2 CFM	1.968 in H2O	Rectangular/Rounded	95 mm	97.1 mm	12 VAC	3	Wire Leads	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	13.2 W	-4 °F	158 °F	57 dB	4850 RPM	33 mm	40000 Hrs	1.1 A	Plastic	13.8 VDC	7 V	Plastic
Sanyo Denki America Inc. 9BMB12K201	0.419 lb	Ball	cURus TUV	Blower	56.8 CFM	5.14 in H2O	Rectangular/Rounded	95 mm	97.1 mm	12 VAC	3	Wire Leads	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	40.8 W	-4 °F	158 °F	66 dB	6850 RPM	33 mm	40000 Hrs	3.4 A	Plastic	13.2 VDC	7 V	Plastic
Sanyo Denki America Inc. 9BMB12H202	0.419 lb	Ball	cURus TUV	Blower	39.2 CFM	1.968 in H2O	Rectangular/Rounded	95 mm	97.1 mm	12 VAC	2 leads	Wire Leads	2 Wire Leads	Locked Rotor Protection	13.2 W	-4 °F	158 °F	57 dB	4850 RPM	33 mm	40000 Hrs	1.1 A	Plastic	13.8 VDC	7 V	Plastic
