Specification	4516513001

Cable Type	Up, Hook, Dual Wall
Conductor Material	Tinned, Copper
Conductor Strand Count	37
Conductor Strand Diameter	0.0091 in
Jacket (Insulation) Diameter	0.082 in
Jacket (Insulation) Material	Polymer
Jacket (Insulation) Thickness	0.008 in
Jacket Color	Red
Length	Enter Number of Feet in Order Quantity
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Spool Size	3281 ft
Voltage	1300 V
Wire Gauge	16 AWG
