Description
General part information
SFDL-S6A-CG1/2
INTERLOCK SOLENOID LOCKING 6PST
Technical Specifications
Parameters and characteristics for this part
| Specification | SFDL-S6A-CG1/2 |
|---|---|
| Actuator Type | Panel Disconnect |
| Approval Agency | cULus, CCC, CE, TUV |
| Circuit | 6PST-4NC/2NO |
| Conduit Thread Size | G1/2 |
| Current Rating | 1 A, 220 mA |
| Features | Manual Override |
| Holding Force | 8 kgf |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Operating Temperature (Max) | 55 °C |
| Operating Temperature (Min) | -10 °C |
| Termination Style | Connector |
| Type | Solenoid Locking |
| Voltage - Supply | 24 VDC |
| Voltage Rating (AC) | 120 VAC |
| Voltage Rating (DC) | 125 VDC |
