FRS-R-450
ActiveEaton - Electronics Division
FUSETRON DUAL ELEMENT FUSE CLASS RK5
FRS-R-450
ActiveEaton - Electronics Division
FUSETRON DUAL ELEMENT FUSE CLASS RK5
Description
General part information
FRS-R-450
450A 600 VAC 300 VDC Fuse Cartridge Requires Holder
Technical Specifications
Parameters and characteristics for this part
| Specification | FRS-R-450 |
|---|---|
| Applications | Electrical, Industrial |
| Approval Agency | CE, UL, CSA |
| Breaking Capacity (AC) | 200 kA |
| Breaking Capacity (DC) | 20 kA |
| Class | RK5 |
| Current Rating | 450 A |
| Fuse Type | Cartridge |
| Mounting Type | Requires Holder |
| Package / Case | Cartridge, Non-Standard |
| Response Time | Slow Blow |
| Size / Dimension Diameter | 2.88 in |
| Size / Dimension Length | 13.38 in |
| Voltage Rating - AC | 600 VAC |
| Voltage Rating - DC | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
