RAC04-15SA/277
ObsoleteRecom Power
AC/DC CONVERTER 15V 4W
RAC04-15SA/277
ObsoleteRecom Power
AC/DC CONVERTER 15V 4W
Description
General part information
RAC04-15SA/277
Enclosed AC DC Converters 1 Output 15V 267mA 90 ~ 305 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | RAC04-15SA/277 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cULus, CE, EN |
| Current - Output (Max) | 267 mA |
| Efficiency | 77 % |
| Features | Universal Input |
| Line Regulation | 0.2 % |
| Load Regulation (Percent) | 0.5 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 6 Leads |
| Package Name | 7-DIP Module |
| Power (Watts) | 4 W |
| Size / Dimension Height | 0.69 in |
| Size / Dimension Length | 1.44 in |
| Size / Dimension Width | 1.07 in |
| Standard Number | 60950-1 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 305 VAC |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Output 1 | 15 V |
| Weight | 0.058 lb |
