5SR472MNFCL
ObsoleteKYOCERA AVX
CAP CER 4700PF 1KV Y5U RADIAL
5SR472MNFCL
ObsoleteKYOCERA AVX
CAP CER 4700PF 1KV Y5U RADIAL
Description
General part information
5SR472MNFCL
4700 pF ±20% 1000V (1kV) Ceramic Capacitor Y5U (E) Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | 5SR472MNFCL |
|---|---|
| Applications | General Purpose |
| Capacitance | 4700 pF |
| Height - Seated (Max) | 0.197 in |
| Lead Spacing | 0.197 in |
| Lead Style | Formed Leads |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -30 °C |
| Package / Case | Disc, Radial |
| Size / Dimension Diameter | 0.354 in |
| Temperature Coefficient | Y5U (E) |
| Tolerance | 20 % |
| Voltage - Rated | 1000 V |
