EWS25-6
ObsoleteTDK Corporation
AC/DC CONVERTER 6V 25W
EWS25-6
ObsoleteTDK Corporation
AC/DC CONVERTER 6V 25W
Description
General part information
EWS25-6
Enclosed AC DC Converters 1 Output 6V 85 ~ 265 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | EWS25-6 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output 1 | 4.2 A |
| Efficiency | 74 % |
| Features | DC Input Capable, Universal Input, Adjustable Output |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -10 °C |
| Power (Watts) | 25 W |
| Size / Dimension Height | 3.82 in |
| Size / Dimension Length | 3.54 in |
| Size / Dimension Width | 1.38 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 265 VAC |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Output 1 | 6 V |
