3-644460-8
ActiveTE Connectivity AMP Connectors
CONN WIRE TO BOARD RCP 9POWER POS 3.96MM IDT RA CABLE MOUNT BAG/BOX
3-644460-8
ActiveTE Connectivity AMP Connectors
CONN WIRE TO BOARD RCP 9POWER POS 3.96MM IDT RA CABLE MOUNT BAG/BOX
Description
General part information
3-644460-8
9 Position, Receptacle, Connector Assembly, Insulation Displacement (IDC), Wire-to-Board, Gold (Au) / Gold Flash over Palladium Nickel, MTA 156
Technical Specifications
Parameters and characteristics for this part
| Specification | 3-644460-8 |
|---|---|
| Cable Termination | IDC |
| Color | Orange |
| Connector Type | Receptacle |
| Contact Finish | Gold |
| Contact Finish Thickness | 30 µin |
| Contact Type | Female Socket |
| Fastening Type | Locking Ramp |
| Features | Closed End, Polarizing Key |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Pitch | 0.156 in |
| Wire Gauge | 18 AWG |
| Wire Type | Ribbon Cable, Discrete |
