1718951
ActivePhoenix Contact
TERM BLOCK 11POS 5MM PCB
1718951
ActivePhoenix Contact
TERM BLOCK 11POS 5MM PCB
Description
General part information
1718951
11 Position Wire to Board Terminal Block 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1718951 |
|---|---|
| Color | Green |
| Current | 15 A |
| Features | Interlocking (Side) |
| Mounting Type | Through Hole |
| Pitch | 0.197 in |
| Positions Per Level | 11 |
| Screw Thread | M3 |
| Torque - Screw (Maximum) | 0.6 Nm |
| Torque - Screw (Minimum) | 0.5 Nm |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 14 AWG |
| Wire Termination | Screw |
