Description
General part information
HT13BN102KN
1000 pF ±10% 50V Ceramic Capacitor C0G, NP0 Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | HT13BN102KN |
|---|---|
| Applications | General Purpose |
| Capacitance | 1000 pF |
| Features | High Temperature |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 200 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Size / Dimension Diameter | 0.135 in |
| Size / Dimension Length | 0.26 in |
| Temperature Coefficient | NP0, C0G |
| Tolerance | 10 % |
| Voltage - Rated | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
