Y2123150R000T159L
ActiveVPG Foil Resistors
V/N 322010 150R000 0.01% 157671
Y2123150R000T159L
ActiveVPG Foil Resistors
V/N 322010 150R000 0.01% 157671
Description
General part information
Y2123150R000T159L
150 Ohms ±0.01% 8W Chip Resistor TO-220-4 Non-Inductive Metal Foil
Technical Specifications
Parameters and characteristics for this part
| Specification | Y2123150R000T159L |
|---|---|
| Composition | Metal Foil |
| Features | Non-Inductive |
| Height - Seated (Max) | 0.158 in |
| Number of Terminations | 4 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | TO-220-4 |
| Package Name | TO-220-4 |
| Power (Watts) | 8 W |
| Resistance | 150 Ohm |
| Size / Dimension Length | 0.4 in |
| Size / Dimension Width | 0.36 in |
| Temperature Coefficient | 0.2 ppm/°C |
| Tolerance | 0.01 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
