MAL224691123E3
ActiveVishay Dale
CAP ALUM 1200UF 20% 50V RADIAL
MAL224691123E3
ActiveVishay Dale
CAP ALUM 1200UF 20% 50V RADIAL
Description
General part information
MAL224691123E3
1200 µF 50 V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 125°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL224691123E3 |
|---|---|
| Applications | Automotive |
| Capacitance | 1200 µF |
| Height - Seated (Max) | 1.319 in |
| Impedance | 27 mOhms |
| Lead Spacing | 0.295 in |
| Lifetime | 6000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Can, Radial |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current | 1.275 A, 2.55 A |
| Size / Dimension Diameter | 0.63 in |
| Tolerance | 20 % |
| Voltage - Rated | 50 V |
