3061994
LTBPhoenix Contact
TERM BLOCK RCPT 24POS STR 3.5MM
3061994
LTBPhoenix Contact
TERM BLOCK RCPT 24POS STR 3.5MM
Description
General part information
3061994
24 Position Terminal Block Receptacle, Female Sockets 0.138" (3.50mm) 180° DIN Rail
Technical Specifications
Parameters and characteristics for this part
| Specification | 3061994 |
|---|---|
| Color | Gray |
| Current - IEC | 17.5 A |
| Features | Rail Mount Foot |
| Mounting Type | DIN Rail |
| Number of Levels | 1 |
| Number of Positions | 24 pos |
| Pitch | 0.138 in |
| Plug Wire Entry Angle | 180 ° |
| Positions Per Level | 24 |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Type | Female Sockets, Receptacle |
| Voltage - IEC | 500 V |
| Wire Gauge or Range - AWG (Max) | 25.5 AWG |
| Wire Gauge or Range - AWG (Min) | 14 AWG |
| Wire Gauge or Range - mm² (Maximum) | 1.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.14 mm² |
