AMT303-V
ObsoleteSame Sky (Formerly CUI Devices)
ROTARY ENCODER INCREMENT PROGPPR
AMT303-V
ObsoleteSame Sky (Formerly CUI Devices)
ROTARY ENCODER INCREMENT PROGPPR
Description
General part information
AMT303-V
Rotary Encoder Incremental 512 Commutation, CW, 10 Pole Right Angle
Technical Specifications
Parameters and characteristics for this part
| Specification | AMT303-V |
|---|---|
| Actuator Stroke (Max) | 8 mm |
| Actuator Stroke (Min) | 2 mm |
| Actuator Type | Open Center |
| Built in Switch | No |
| Detent | No |
| Encoder Type | Incremental |
| Mounting Type | Chassis Mount, Motors |
| Orientation | Right Angle |
| Output Type | Commutation, 4 Pole, CCW, CW, 8 Pole, 10 Pole, 6 Pole |
| Pulses per Revolution | 250, 512, 800, 200 |
| Pulses per Revolution | Programmable |
| Termination Style | Terminal Pins |
| Voltage - Supply | 5 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
