Description
General part information
LFXTAL003210BULK
12 MHz ±30ppm Crystal 16pF 40 Ohms HC-49/US
Technical Specifications
Parameters and characteristics for this part
| Specification | LFXTAL003210BULK |
|---|---|
| ESR (Equivalent Series Resistance) | 40 Ohm |
| Frequency | 12 MHz |
| Frequency Stability | 50 ppm |
| Frequency Tolerance | 30 ppm |
| Height - Seated (Max) | 0.169 in |
| Load Capacitance | 16 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -10 °C |
| Package / Case | HC-49/US |
| Size / Dimension Length | 0.449 in |
| Size / Dimension Width | 0.15 in |
| Type | MHz Crystal |
