L000410-03
ActiveTE Connectivity AMP Connectors
MONOPOLE WHIP,UHF,470-512MHZ
L000410-03
ActiveTE Connectivity AMP Connectors
MONOPOLE WHIP,UHF,470-512MHZ
Description
General part information
L000410-03
Whip Antenna, Single Band, External Mount, Screw Mount, Omnidirectional
Technical Specifications
Parameters and characteristics for this part
| Specification | L000410-03 |
|---|---|
| Antenna Type | Straight, Whip |
| Applications | General Purpose |
| Features | 5m, Cable |
| Frequency (Center/Band) | 491 MHz |
| Frequency Group | UHF |
| Frequency Group Maximum (UHF) | 1 GHz |
| Frequency Group Minimum (UHF) | 300 MHz |
| Frequency Range (Max) | 512 MHz |
| Frequency Range (Min) | 470 MHz |
| Gain | 5.17 dBi |
| Height (Max) | 4.409 in |
| Ingress Protection | IP67 |
| Mounting Type | Connector Mount |
| Number of Bands | 1 |
| Power - Max | 45 W |
| RF Family/Standard | General ISM |
| VSWR | 1.6 |
