L101374SP-25
ActiveITG Electronics, Inc.
RESONANT INDUCTOR 22UH 32.5A 6M
L101374SP-25
ActiveITG Electronics, Inc.
RESONANT INDUCTOR 22UH 32.5A 6M
Description
General part information
L101374SP-25
22 µH Unshielded Wirewound Inductor 28 A 6mOhm Max Radial, Vertical
Technical Specifications
Parameters and characteristics for this part
| Specification | L101374SP-25 |
|---|---|
| Current - Saturation (Isat) | 26.5 A |
| Current Rating | 28 A |
| DC Resistance (DCR) (Max) | 6 mOhm |
| Height - Seated (Max) | 1.102 in |
| Inductance | 22 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 130 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Vertical |
| Package Name | Radial |
| Shielding | Unshielded |
| Size / Dimension Length | 1.319 in |
| Size / Dimension Width | 1.201 in |
| Tolerance | 10 % |
| Type | Wirewound |
