CFM-4010B-050-195
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 40X10.5MM 5VDC WIRE
CFM-4010B-050-195
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 40X10.5MM 5VDC WIRE
Description
General part information
CFM-4010B-050-195
Fan Tubeaxial 5VDC Square - 40mm L x 40mm H Ball 4.2 CFM (0.118mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-4010B-050-195 |
|---|---|
| Air Flow | 4.2 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 0.08 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 19.5 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 0.4 W |
| RPM | 5000 RPM |
| Size / Dimension Height | 40 mm |
| Size / Dimension Length | 40 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.07 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 5 VAC |
| Voltage Range (Max) | 5.5 VDC |
| Voltage Range (Min) | 4.5 VDC |
| Width | 10.5 mm |
