B82442H1102K000
ObsoleteEPCOS - TDK Electronics
FIXED IND 1UH 2.5A 24 MOHM SMD
B82442H1102K000
ObsoleteEPCOS - TDK Electronics
FIXED IND 1UH 2.5A 24 MOHM SMD
Description
General part information
B82442H1102K000
1 µH Unshielded Drum Core, Wirewound Inductor 2.5 A 24mOhm Max 2-SMD, J-Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | B82442H1102K000 |
|---|---|
| Current Rating | 2.5 A |
| DC Resistance (DCR) (Max) | 24 mOhm |
| Frequency - Self Resonant | 95 MHz |
| Height - Seated (Max) | 0.209 in |
| Inductance | 1 µH |
| Inductance Frequency - Test | 7.96 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2-SMD, J-Lead |
| Package Name | 2220 (5650 Metric) |
| Q | 10 |
| Ratings | AEC-Q200 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.22 in |
| Size / Dimension Width | 0.197 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
