UCC-JAR500
Unknown3M Electronic Specialty
CONN SPLICE 22-26 AWG IDC 1=1JAR
UCC-JAR500
Unknown3M Electronic Specialty
CONN SPLICE 22-26 AWG IDC 1=1JAR
Description
General part information
UCC-JAR500
Terminal Butt Splice, Closed End, Individual Openings Connector IDC 22-26 AWG
Technical Specifications
Parameters and characteristics for this part
| Specification | UCC-JAR500 |
|---|---|
| Features | Gel Filled |
| Insulation | Fully Insulated |
| Number of Wire Entries | 2 |
| Terminal Type | Closed End, Individual Openings, Butt Splice |
| Termination | IDC |
| Wire Gauge (AWG) (Max) | 26 AWG |
| Wire Gauge (AWG) (Min) | 22 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
