PEWK3920D4L00Q9
ActiveC&B Eureka Innovations
0.004 OHM 0.5% 4W 50PPM/C
PEWK3920D4L00Q9
ActiveC&B Eureka Innovations
0.004 OHM 0.5% 4W 50PPM/C
Description
General part information
PEWK3920D4L00Q9
4 mOhms ±0.5% 4W Chip Resistor 3920 (1052 Metric) Automotive AEC-Q200, Current Sense Metal Element
Technical Specifications
Parameters and characteristics for this part
| Specification | PEWK3920D4L00Q9 |
|---|---|
| Composition | Metal Element |
| Features | Current Sense, Automotive AEC-Q200 |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 170 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 3920 (1052 Metric) |
| Package Name | 3920 |
| Power (Watts) | 4 W |
| Ratings | AEC-Q200 |
| Resistance | 4 mOhms |
| Size / Dimension Length | 0.394 in |
| Size / Dimension Width | 0.205 in |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 0.5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
