Description
General part information
BTS200-MDTD
Retroreflective Optical Sensor 0.394" ~ 7.874" (10mm ~ 200mm) NPN - Open Collector/Dark-ON
Technical Specifications
Parameters and characteristics for this part
| Specification | BTS200-MDTD |
|---|---|
| Adjustment Type | Adjustable |
| Cable Length | 78.7 in, 78.74 in |
| Connection Method | Cable |
| Ingress Protection | IP67 |
| Light Source | Red |
| Light Source Wavelength (Red) | 650 nm |
| Operating Temperature (Max) | 55 °C, 55 °C |
| Operating Temperature (Min) | -20 °C, -20 °C |
| Output Configuration | NPN - Open Collector, Dark-ON |
| Response Time | 1 ms |
| Sensing Distance Maximum | 7.874 " |
| Sensing Distance Minimum | 0.394 " |
| Sensing Method | Retroreflective |
| Voltage - Supply (Maximum) | 24 VAC |
| Voltage - Supply (Minimum) | 12 VDC |
