IHLP2525CZEKR68M01
ActiveVishay Dale
FIXED IND 680NH 15.5A 5.5MOHM SM
IHLP2525CZEKR68M01
ActiveVishay Dale
FIXED IND 680NH 15.5A 5.5MOHM SM
Description
General part information
IHLP2525CZEKR68M01
FIXED IND 680NH 15.5A 5.5MOHM SM
Technical Specifications
Parameters and characteristics for this part
| Specification | IHLP2525CZEKR68M01 |
|---|---|
| Current - Saturation (Isat) | 25 A |
| Current Rating | 15.5 A |
| DC Resistance (DCR) (Max) | 5.5 mOhm |
| Frequency - Self Resonant | 62 MHz |
| Height - Seated (Max) | 0.118 in |
| Inductance | 680 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.27 in |
| Size / Dimension Width | 0.255 in |
| Tolerance | 20 % |
| Type | Molded |
