OPB750T
ActiveTT Electronics/BI
SENSR OPTO TRANS 5.59MM REFL PCB
OPB750T
ActiveTT Electronics/BI
SENSR OPTO TRANS 5.59MM REFL PCB
Description
General part information
OPB750T
SENSR OPTO TRANS 5.59MM REFL PCB
Technical Specifications
Parameters and characteristics for this part
| Specification | OPB750T |
|---|---|
| Current - Collector (Ic) (Max) | 0.03 mA |
| Current - DC Forward (If) (Max) | 50 mA |
| Mounting Type | Through Hole |
| Output Type | Phototransistor |
| Package / Case | PCB Mount |
| Sensing Distance | 0.22 " |
| Sensing Method | Reflective |
| Voltage - Collector Emitter Breakdown (Max) | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
Declaration of Mineral Conflict Free Material for Juarez Site
Quality Manual for Juarez Site
Conflict Minerals Policy for Juarez Site
App Note 248: Connecting and Using Infrared Optoelectronics
Custom Optoelectronic Assemblies Tri-Fold
App Note: Optoelectronic Sensors for Electric Power Metering
Supplier Quality Requirements Manual
Optoelectronics for Medical Tri-Fold
REACH Compliance for Juarez Site
Sensors Product Selection Guide
Juarez ISO 9001
Optoelectronics One Pager
App Note 247: Reflective Assemblies
App Note 249: Slotted and Reflective Switches
Lead Free and RoHs Compliance for Juarez Site
OPB750 755
RoHs Letter for Juarez Site
RoHs 3 Declaration Form for Juarez Site
