MCOT256064BA-WM
ActiveMidas Displays
256X64 TAB OLED, WHITE ON BLACK
MCOT256064BA-WM
ActiveMidas Displays
256X64 TAB OLED, WHITE ON BLACK
Description
General part information
MCOT256064BA-WM
Graphic LCD Display Module Transmissive White OLED Parallel, SPI 3.12" (79.25mm) 256 x 64
Technical Specifications
Parameters and characteristics for this part
| Specification | MCOT256064BA-WM |
|---|---|
| Background Color | Black |
| Backlight Color | White |
| Backlight Type | LED |
| Controller Type | SSD1322 |
| Diagonal Screen Size | 3.12 in |
| Display Mode | Transmissive |
| Display Type | OLED |
| Dot Pixels (Horizontal) | 256 pixels |
| Dot Pixels (Vertical) | 64 pixels |
| Graphics Color | White |
| Interface | Parallel, SPI |
| Touchscreen | Non-Touch |
| Viewing Area Height | 21.18 mm |
| Viewing Area Width | 78.78 mm |
