033TBSDATCS2
ActiveCTS Electrocomponents
SWITCH TOGGLE DPDT 3A 120V
033TBSDATCS2
ActiveCTS Electrocomponents
SWITCH TOGGLE DPDT 3A 120V
Description
General part information
033TBSDATCS2
Toggle Switch DPDT Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 033TBSDATCS2 |
|---|---|
| Actuator Length | 6.1 mm |
| Actuator Type | Standard Round |
| Bushing Thread | Unthreaded |
| Circuit | DPDT |
| Current Rating | 3 A |
| Electrical Life (Cycles) | 30000 Cycles |
| Illumination | Non-Illuminated |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| Switch Function | On-On |
| Termination Style | PC Pin |
| Voltage Rating - AC | 120 V |
| Voltage Rating - DC | 28 V |
