Description
General part information
SER0062
Positional Rotation DC Motor Servomotor, RC (Hobby) 6 ~ 8.4VDC
Technical Specifications
Parameters and characteristics for this part
| Specification | SER0062 |
|---|---|
| Function | RC (Hobby), Servomotor |
| Motor Type | Positional Rotation |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -20 °C |
| Termination Style | Wire Leads with Connector |
| Torque - Max Momentary (mNm) | 4412.99 mNm |
| Torque - Max Momentary (oz-in) | 624.93 oz-in |
| Torque - Rated (mNm) | 3432 mNm |
| Torque - Rated (oz-in) | 486.1 oz-in |
| Type | DC Motor |
| Voltage - Rated (Max) | 8.4 VDC |
| Voltage - Rated (Min) | 6 V |
