Description
General part information
SUINT1500LCD2UN
208/230V 1500VA 1350W DOUBLE-CON
Technical Specifications
Parameters and characteristics for this part
| Specification | SUINT1500LCD2UN |
|---|---|
| AC Outlets (Count) | 6 count |
| Applications | Network, Single Phase |
| Approval Agency | EAC, CE, UL, CSA, SASO |
| Backup Time - Max Load | 4.5 minutes |
| Form | Rackmount |
| Height | 3.46 in |
| Input Connector | C14 |
| Media Lines Protected | RS-232 |
| Output Connector | C13 |
| Output Connector Pin Count | 6 Pin |
| Power - Rated (VA) | 1.5 kVA |
| Power - Rated (W) | 1350 W |
| Size / Dimension Length | 19.53 in |
| Size / Dimension Width | 17.24 in |
| Type | Online (Double Conversion) |
| Voltage - Input | 240 VAC, 230 V, 220 VDC, 200 VAC, 208 VAC |
| Voltage - Output | 200 V, 230 V, 208 V, 240 V, 220 V |
| Voltage - Output | 220V, 230V, 200V, 208V, 240V |
| Voltage - Output (1) | 200 V |
| Voltage - Output (2) | 208 V |
| Voltage - Output (3) | 220 V |
| Voltage - Output (4) | 230 V |
| Voltage - Output (5) | 240 V |
