Specification	WVM911RL

Circuit	SPDT (1 Form C)
Contact Rating (Current)	10 A
Delay Time (Maximum)	30 Sec
Delay Time (Minimum)	0.25 Sec
Mounting Type	Chassis Mount
Operating Temperature (Max)	65 °C
Operating Temperature (Min)	-40 °C
Output Type	Relay
Trip Status	Low, Energized High
Trip Voltage (Max)	480 V
Trip Voltage (Min)	400 V
Type	Voltage Sensing AC, Phase Loss
Voltage - Supply (Maximum)	480 VAC
Voltage - Supply (Minimum)	400 VAC
