VTX-110-047
ActiveVigortronix
PULSE XFMR OPEN 2:1
VTX-110-047
ActiveVigortronix
PULSE XFMR OPEN 2:1
Description
General part information
VTX-110-047
12mH, 3mH General Purpose Pulse Transformer 2:1 Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-110-047 |
|---|---|
| ET (Volt-Time) | 200 VµS |
| Height - Seated (Max) | 0.551 in |
| Inductance (Option 1) | 12 mH |
| Inductance (Option 2) | 3 mH |
| Mounting Type | Through Hole |
| Size / Dimension Length | 0.512 in |
| Size / Dimension Width | 0.512 in |
| Transformer Type | General Purpose |
| Turns Ratio - Primary | 2 |
| Turns Ratio - Secondary | 1 |
