MPS-200-24
ObsoleteMEAN WELL USA Inc.
AC/DC CONVERTER 24V 142W
MPS-200-24
ObsoleteMEAN WELL USA Inc.
AC/DC CONVERTER 24V 142W
Description
General part information
MPS-200-24
Open Frame AC DC Converters 1 Output 24V 90 ~ 264 VAC, 127 ~ 370 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | MPS-200-24 |
|---|---|
| Applications | Medical |
| Approval Agency | cURus, CB, TUV, CE |
| Current - Output 1 | 5.9 A |
| Efficiency | 86 % |
| Features | Adjustable Output, Remote On/Off, Remote Sense, Universal Input |
| Minimum Load Required | No |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Power (Watts) | 202 W, 142 W |
| Size / Dimension Height | 1.4 in |
| Size / Dimension Length | 7 in |
| Size / Dimension Width | 4.22 in |
| Type | Open Frame |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Input (DC) Maximum | 370 V |
| Voltage - Input (DC) Minimum | 127 VDC |
| Voltage - Isolation | 4000 Vpk |
| Voltage - Output 1 | 24 V |
