RAC10-3.3SA-ST
ObsoleteRecom Power
AC/DC CONVERTER 3.3V 10W
RAC10-3.3SA-ST
ObsoleteRecom Power
AC/DC CONVERTER 3.3V 10W
Description
General part information
RAC10-3.3SA-ST
Enclosed AC DC Converters 1 Output 3.3V 90 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | RAC10-3.3SA-ST |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, CE |
| Current - Output 1 | 3 A |
| Efficiency | 65 % |
| Features | Universal Input, DC Input Capable |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Power (Watts) | 10 W |
| Size / Dimension Height | 1.06 in |
| Size / Dimension Length | 3.78 in |
| Size / Dimension Width | 2.12 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 3.3 V |
