N318-06M
ActiveEaton Tripp Lite
NETWORK CABLE, LC DUPLEX TO ST DUPLEX, 6 M, 20 FT, ORANGE
N318-06M
ActiveEaton Tripp Lite
NETWORK CABLE, LC DUPLEX TO ST DUPLEX, 6 M, 20 FT, ORANGE
Description
General part information
N318-06M
Cable Fiber Optic LC Duplex To ST (2) 62.5/125 19.7' (6.0m)
Technical Specifications
Parameters and characteristics for this part
| Specification | N318-06M |
|---|---|
| 1st Connector | LC Duplex |
| 2nd Connector | ST |
| 2nd Connector Count | 2 pcs |
| Cable Type | Twin Zip |
| Color - Cable | Orange |
| Color - Connectors | Black, Red, Beige |
| Features | Zipcord, Riser |
| Fiber Cladding Diameter | 125 µm |
| Fiber Core Diameter | 62.5 µm |
| Insertion Loss | 0.2 dB |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Length - Overall | 19.7 ft |
| Ratings | FDDI, OFNR |
| Type | Multimode, Duplex |
