3148BE
ActiveKanebridge
ELEVATOR BOLT - SQUARE NECK WIDE
3148BE
ActiveKanebridge
ELEVATOR BOLT - SQUARE NECK WIDE
Description
General part information
3148BE
5/16"-18 Flat Head Elevator Bolt Drive Steel
Technical Specifications
Parameters and characteristics for this part
| Specification | 3148BE |
|---|---|
| Features | Wide |
| Head Diameter | 1.192 inches |
| Head Height | 0.104 in |
| Length - Below Head | 3 in |
| Length - Overall | 3.104 in |
| Material | Steel |
| Plating | Zinc |
| Screw Head Type | Flat Head |
| Thread Pitch (TPI) | 18 TPI |
| Thread Size (Nominal) | 0.3125 in |
| Type | Elevator Bolt |
