CDB2300-DC-LCO-CP

Obsolete

Cirrus Logic Inc.

BOARD EVAL GEN PURPOSE PLL

Search across all available documentation for this part.

Obsolete

Cirrus Logic Inc.

BOARD EVAL GEN PURPOSE PLL

Technical Specifications

Parameters and characteristics for this part

Specification	CDB2300-DC-LCO-CP

Embedded	False
Function	Clock Generator
Primary Attributes	Fractional-N, Low Jitter Clock Synthesizer, Clock Multiplier
Primary Attributes [Max]	75 MHz
Primary Attributes [Min]	6 MHz
Secondary Attributes	I2C, SPI, USB
Supplied Contents	Board(s)
Type	Timing
Utilized IC / Part	CS2300

BOARD EVAL GEN PURPOSE PLL

Part	Supplied Contents	Primary Attributes	Primary Attributes [Max]	Primary Attributes [Min]	Function	Embedded	Type	Secondary Attributes	Utilized IC / Part
Cirrus Logic Inc. CDB2300-DC-LCO-CP	Board(s)	Clock Multiplier, Fractional-N, Low Jitter Clock Synthesizer	75 MHz	6 MHz	Clock Generator		Timing	I2C, SPI, USB	CS2300

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 25.00

General part information

CS2300 Clock Generator Timing Evaluation Board
