LK4301-9ERG

Active

Bel Power Solutions

AC/DC CONVERTER 12V 280W

Search across all available documentation for this part.

Active

Bel Power Solutions

AC/DC CONVERTER 12V 280W

Technical Specifications

Parameters and characteristics for this part

Specification	LK4301-9ERG

Applications	Railway, ITE (Commercial)
Approval Agency	cCSAus, CE, NEMKO
Current - Output 1	12 A
Efficiency	84 %
Features	Load Sharing, PFC, Remote On/Off, Adjustable Output, Universal Input
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	71 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	280 W
Size / Dimension [x]	168 mm
Size / Dimension [x]	6.6 "
Size / Dimension [y]	111 mm
Size / Dimension [y]	4.4 "
Size / Dimension [z]	3.2 in
Size / Dimension [z]	80 mm
Type	Conformal Coated, Enclosed
Voltage - Isolation	2.8 kV
Voltage - Output 1	12 V

AC/DC CONVERTER 12V 280W

Part	Type	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Approval Agency	Number of Outputs	Features	Current - Output 1	Mounting Type	Efficiency	Voltage - Output 1	Power (Watts)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
Bel Power Solutions LK4301-9ERG	Conformal Coated, Enclosed	ITE (Commercial), Railway	-40 °C	71 °C	2.8 kV	cCSAus, CE, NEMKO	1	Adjustable Output, Load Sharing, PFC, Remote On/Off, Universal Input	12 A	Chassis Mount	84 %	12 V	280 W	168 mm	111 mm	3.2 in	80 mm	6.6 "	4.4 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 1171.60

General part information

Enclosed, Conformal Coated AC DC Converters 1 Output 12V 85 ~ 264 VAC Input
