Specification	427-2-5

Adhesive	Acrylic
Backing, Carrier	Aluminum, Dead Soft
Color	Silver
Length (ft)	15 ft
Length (yd)	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	80 °F
Storage/Refrigeration Temperature (Minimum)	60 °F
Tape Type	Aluminum Foil
Temperature Range (Max)	300 °F
Temperature Range (Min)	-65 °F
Thickness	0.0046 in
Thickness - Adhesive	0.0018 in
Thickness - Backing, Carrier	0.0028 in
Usage	Reflection, Heat Dissipation
Width	2 in

427 Series

...

Part	Storage/Refrigeration Temperature (Maximum)	Storage/Refrigeration Temperature (Minimum)	Shelf Life	Shelf Life Start	Width	Temperature Range (Min)	Temperature Range (Max)	Thickness - Adhesive	Length	Thickness	Adhesive	Backing, Carrier	Thickness - Backing, Carrier	Tape Type	Color	Length (ft)	Length (yd)
3M (TC) 3M 427 10.5" X 1.25"-25	80 °F	60 °F	24 Months	Date of Manufacture	10.5 in	-65 °F	300 °F	0.0018 in	1.25 in	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 0.5" X 9"-250	80 °F	60 °F	24 Months	Date of Manufacture	12.7 mm	-65 °F	300 °F	0.0018 in	228.6 mm	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 2.75" X 60YD	80 °F	60 °F	24 Months	Date of Manufacture	2.75 in	-65 °F	300 °F	0.0018 in		0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver	180 ft	60 yd
3M (TC) 3M 427 2" X 2"-100	80 °F	60 °F	24 Months	Date of Manufacture	2 in	-65 °F	300 °F	0.0018 in	2 in	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 CIRCLE-0.563"-2000	80 °F	60 °F	24 Months	Date of Manufacture	0.56 in	-65 °F	300 °F	0.0018 in		0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 7" X 9.25"-25	80 °F	60 °F	24 Months	Date of Manufacture	7 in	-65 °F	300 °F	0.0018 in	9.25 "	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 7.25" X 8"-25	80 °F	60 °F	24 Months	Date of Manufacture	7.25 in	-65 °F	300 °F	0.0018 in	8 in	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 1.5" X 2"-100	80 °F	60 °F	24 Months	Date of Manufacture	1.5 in	-65 °F	300 °F	0.0018 in	2 in	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 3M 427 1.5" X 6"-100	80 °F	60 °F	24 Months	Date of Manufacture	1.5 in	-65 °F	300 °F	0.0018 in	0.5 ft	0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver
3M (TC) 427-5-60	80 °F	60 °F	24 Months	Date of Manufacture	5 in	-65 °F	300 °F	0.0018 in		0.0046 in	Acrylic	Aluminum Dead Soft	0.0028 in	Aluminum Foil	Silver	180 ft	60 yd
