BFLY-PGE-23S6C-C
ActiveFLIR Integrated Imaging Solutions, Inc.
2.3MP COLOR PGE 1/1.2" C-MOUNT
BFLY-PGE-23S6C-C
ActiveFLIR Integrated Imaging Solutions, Inc.
2.3MP COLOR PGE 1/1.2" C-MOUNT
Description
General part information
BFLY-PGE-23S6C-C
2.3MP COLOR PGE 1/1.2" C-MOUNT
Technical Specifications
Parameters and characteristics for this part
| Specification | BFLY-PGE-23S6C-C |
|---|---|
| Color | RGB |
| Frames per Second | 41 fps |
| Height (Max) | 1.154 in |
| Interface | GigE |
| Lens Mount | C |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Package Name | Module |
| Pixel Size (Length) | 5.86 µm |
| Pixel Size (Width) | 5.86 µm |
| Resolution Height | 1200 |
| Resolution Width | 1920 |
| Sensor | IMX249 |
| Shutter | Global |
| Size / Dimension Length | 1.142 in |
| Size / Dimension Width | 1.181 in |
| Type | CMOS |
