ARG120C 10R J

Active

Ohmite

RES CHAS MNT 10 OHM 5% 150W

Search across all available documentation for this part.

Active

Ohmite

RES CHAS MNT 10 OHM 5% 150W

Technical Specifications

Parameters and characteristics commom to parts in this series

RES CHAS MNT 10 OHM 5% 150W

Part	Lead Style	Package / Case	Composition	Operating Temperature [Max]	Operating Temperature [Min]	Resistance	Mounting Feature	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Coating, Housing Type	Power (Watts)	Temperature Coefficient	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Tolerance
Ohmite ARG120C 10R J	Wire Leads	Rectangular, Wire Leads	Wirewound	250 °C	0 °C	10 Ohms	Screw Holes	1.102 in	28 mm	Aluminum	150 W	150 ppm/°C	3.543 "	1.437 in	36.5 mm	90 mm	5 %
Ohmite ARG120C 2R J	Wire Leads	Rectangular, Wire Leads	Wirewound	250 °C	0 °C	2 Ohms	Screw Holes	1.102 in	28 mm	Aluminum	150 W	150 ppm/°C	3.543 "	1.437 in	36.5 mm	90 mm	5 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Ohms ±5% 150W Wirewound Chassis Mount Resistor

Technical documentation and resources

No documents available
