PUP6AHD04OR-G
ActivePanduit Corp
CABLE CAT6A 8COND 23AWG 1000'
PUP6AHD04OR-G
ActivePanduit Corp
CABLE CAT6A 8COND 23AWG 1000'
Description
General part information
PUP6AHD04OR-G
8 (4 Pair Twisted) Conductor Multi-Pair, Cat6a Cable Orange 23 AWG 1000.0' (304.8m)
Technical Specifications
Parameters and characteristics for this part
| Specification | PUP6AHD04OR-G |
|---|---|
| Cable Type | Multi-Pair, Cat6A |
| Conductor Arrangement | Twisted |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP) |
| Conductor Material | Copper |
| Conductor Strand | Solid |
| Jacket (Insulation) Diameter | 0.23 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Plenum |
| Jacket Color | Orange |
| Length | 1000 ft |
| Number of Conductors | 8 |
| Number of Conductors - Pair | 4 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -20 °C |
| Voltage | 80 V |
| Wire Gauge | 23 AWG |
