SRP3020C-5R6M
ObsoleteBourns Inc.
FIXED IND 5.6UH 1.7A 238MOHM SMD
SRP3020C-5R6M
ObsoleteBourns Inc.
FIXED IND 5.6UH 1.7A 238MOHM SMD
Description
General part information
SRP3020C-5R6M
5.6 µH Shielded Inductor 1.7 A 238mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP3020C-5R6M |
|---|---|
| Current - Saturation (Isat) | 1.9 A |
| Current Rating | 1.7 A |
| DC Resistance (DCR) (Max) | 238 mOhm |
| Frequency - Self Resonant | 28 MHz |
| Height - Seated (Max) | 0.079 in |
| Inductance | 5.6 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 10 |
| Shielding | Shielded |
| Size / Dimension Length | 0.138 in |
| Size / Dimension Width | 0.126 in |
| Tolerance | 20 % |
