DS2781EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR DS2781
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
DS2781EVKIT+
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR DS2781
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS2781EVKIT+ | DS2781 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Function | Battery Monitor | Battery Monitor |
| Interface | - | 1-Wire |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 2 cells |
| Number of Cells | - | 1 |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | -20 °C |
| Package / Case | - | 8-TSSOP, 10-WFDFN Exposed Pad |
| Package / Case | - | 0.173 " |
| Package / Case | - | 4.4 mm |
| Secondary Attributes | USB Interface(s) | USB Interface(s) |
| Supplied Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Supplier Device Package | - | 8-TSSOP, 10-TDFN (3x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | DS2781 | DS2781 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 94.37 | |
| 10 | $ 94.83 | |||
| 25 | $ 94.74 | |||
| 100 | $ 94.61 | |||
DS2781 Series
IC BATT MON LI-ION 1-2CEL 8TSSOP
| Part | Interface | Number of Cells [Max] | Number of Cells [Min] | Battery Chemistry | Function | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Package / Case | Package / Case [custom] | Package / Case [custom] | Supplier Device Package | Contents | Secondary Attributes | Utilized IC / Part | Supplied Contents | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS2781E+T&R | 1-Wire | 2 cells | 1 | Lithium Ion/Polymer | Battery Monitor | 70 °C | -20 °C | Surface Mount | 8-TSSOP | 0.173 " | 4.4 mm | 8-TSSOP | |||||
Analog Devices Inc./Maxim Integrated DS2781EVKIT+ | Battery Monitor | Board(s), Cable(s) | USB Interface(s) | DS2781 | Board(s), Cable(s) | Power Management | |||||||||||
Analog Devices Inc./Maxim Integrated DS2781E+ | 1-Wire | 2 cells | 1 | Lithium Ion/Polymer | Battery Monitor | 70 °C | -20 °C | Surface Mount | 8-TSSOP | 0.173 " | 4.4 mm | 8-TSSOP | |||||
Analog Devices Inc./Maxim Integrated DS2781G+ | 1-Wire | 2 cells | 1 | Lithium Ion/Polymer | Battery Monitor | 70 °C | -20 °C | Surface Mount | 10-WFDFN Exposed Pad | 10-TDFN (3x4) |
