TA3FLWX

Active

Switchcraft Inc.

CONN PLUG FMALE MINI XLR 3P SLDR

Search across all available documentation for this part.

Active

Switchcraft Inc.

CONN PLUG FMALE MINI XLR 3P SLDR

Technical Specifications

Parameters and characteristics for this part

CONN PLUG FMALE MINI XLR 3P SLDR

Part	Voltage Rating	Orientation	Shell Finish	Mounting Type	Fastening Type	Backshell Material, Plating	Color	Features	Shielding	Shell Size - Insert	Contact Material	Applications	Connector Type	Primary Material	Shell Material	Operating Temperature [Max]	Operating Temperature [Min]	Insert Material	Termination	Contact Finish - Mating	Cable Opening [custom]	Cable Opening [custom]	Current Rating (Amps)
Switchcraft Inc. TA3FLWX	125 VAC	Keyed	Nickel	Free Hanging (In-Line)	Latch Lock	Thermoplastic	Silver, White	Backshell, Cable Clamp	Shielded	Mini XLR	Copper Alloy	Audio	Female Sockets, Plug	Metal	Copper Alloy	85 °C	-55 °C	Thermoplastic	Solder	Silver	4.32 mm	0.17 in	5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug, Female Sockets Solder
