IL19-C20-H05-3150-100-O
ActiveTE Connectivity AMP Connectors
IL19-C20-H05-3150-100-O
IL19-C20-H05-3150-100-O
ActiveTE Connectivity AMP Connectors
IL19-C20-H05-3150-100-O
Description
General part information
IL19-C20-H05-3150-100-O
250 VAC, 16 A, 100 mm [3.93 in], IP20, UL 94V-2, 3, 1.5 – .15 mm² Wire, Orange, IEC Power Cords
Technical Specifications
Parameters and characteristics for this part
| Specification | IL19-C20-H05-3150-100-O |
|---|---|
| 1st Connector | IEC 320-C20 |
| 2nd Connector | IEC 320-C19 |
| Color | Orange |
| Cord Type | H05VV-F |
| Current Rating | 16 A |
| Length | 3.28 ft |
| Number of Conductors | 3 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Shielding | Unshielded |
| Style | Female Sockets (Slots), Male Pins (Blades) |
| Voltage Rating | 250 V |
| Wire Gauge | 16 AWG |
