XMLK030P2D23
ActiveSCHNEIDER ELECTRIC
PRESSURE TX, DIFFERENTIAL, 0-30PSI
XMLK030P2D23
ActiveSCHNEIDER ELECTRIC
PRESSURE TX, DIFFERENTIAL, 0-30PSI
Description
General part information
XMLK030P2D23
PRESSURE TX, DIFFERENTIAL, 0-30PSI
Technical Specifications
Parameters and characteristics for this part
| Specification | XMLK030P2D23 |
|---|---|
| Accuracy | 1 % |
| Applications | Industrial Automation |
| Maximum Pressure | 60 PSI |
| Operating Pressure | 30 PSI |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | 0 °C |
| Output Current (Max) | 20 mA |
| Output Current (Min) | 4 mA |
| Output Type | Analog Current |
| Package / Case | Threaded, Cylinder |
| Port Diameter | 0.25 " |
| Port Feature | NPT |
| Port Gender | Male |
| Port Style | Threaded |
| Termination Style | Connector |
| Voltage - Supply (Maximum) | 33 V |
| Voltage - Supply (Minimum) | 8 V |
