UB1-20RF1
ActiveBourns Inc.
UB-1 20 OHM 1% HIREL
UB1-20RF1
ActiveBourns Inc.
UB-1 20 OHM 1% HIREL
Description
General part information
UB1-20RF1
UB-1 20 OHM 1% HIREL
Technical Specifications
Parameters and characteristics for this part
| Specification | UB1-20RF1 |
|---|---|
| Composition | Wirewound |
| Features | Moisture Resistant, Pulse Withstanding |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 250 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 1 W |
| Resistance | 20 Ohm |
| Size / Dimension Diameter | 0.087 in |
| Size / Dimension Length | 0.252 in |
| Temperature Coefficient | 20 ppm/¯C |
| Tolerance | 1 % |
