Specification	1424843

Connector Type	Hood - Coupling
Features	Cable to Cable, Salt Water Resistant
Housing Color	Gray
Housing Material	Die Cast, Aluminum
Ingress Protection Description	Dust Tight, Waterproof, Water Resistant
Ingress Protection IP Rating	IP67, IP66
Lock Location	Locking Clip (2) on Hood Top
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Size	B32
Size / Dimension Height	3.929 in
Size / Dimension Length	3.701 in
Size / Dimension Width	3.248 in
Style	Bottom Entry, Top or Bottom Entry
Thread Size	M40
